Custom Truck Bodies

STANDARD CONSTRUCTION

• Available in any length, available in 96”W or 102”W
• 3⁄16” floor
• Industrial enamel primer & paint
• Containers are delivered ready for use. Including: Caution/Warning decals, D.O.T. Reflective Tape & any Customer supplied decals

Understructure – Rolloffs

• 3”H Structural channel 18” on center, with full 2”x3”x3/16” apron on Dump Bodies
• 1¼” Thick solid bullnose inserted 2” into rails into 2”x6”x3⁄16” rails

Hook Styles

• Cable-1½” Cable hook with ¾” thick plate & 4”Dia.x6”W Front Rollers with grease zerks & ½” thick support
• Hook-2”x6”x3⁄16” A-frame with 2½” Dia. pin/bar & 5⁄8” thick hook plates
• Deadlift

Available Options

• Chain Hangers on Bulkhead
• Tool Boxes & Power Winch
• Heavy-duty 2”x6” Outer Rail Tubes
• 2”x5” Skids with1”x2” Liners
• 8” Dia.x10”W Rear Rollers
• Bulkhead: Expanded or Solid Steel
• D-ring Tie Downs
